TFT Module

  Solomon Goldentek Display is a global leading Manufacturer of TFT LCD display based in Taiwan. We offers a wide product range of small to medium sizes TFT display modules. Feel free to inquired by selecting product of interest and press the inquiry button below. SGD TFT displays are qualified under industrial standard including standard TFT-LCD modules, High brightness TFT LCD (sunlight readable display), TFT panels with controller boards, and Wide Temperature TFT LCD. These displays are available in various resolutions as well as touch screen optional in resistive and capacitive technology. Many of our TFT display modules have more than one interface available including MCU, RGB, TTL and LVDS. SGD TFT modules are qualified for applications including industrial control, coffee machine, medical equipment, POS system, automation, GPS navigator, energy control, telecoms, medical equipment and many more.

Small size

Select Size Part Number Resolution Display Area
(mm)
Outer Dimension
(L*W*T/MM)
Viewing Angle Connection Connector Type B/L Brightness
(cd/m2)
1.44" GATC14NNJB1E0 128*128 25.4976*26.496mm 29.0*34.69*2.6mm 6 CPU(8 Bits) 0.8mmx32pin FPC(Hotbar) 120
1.44" GATC14TNJD1E0 128*128 25.4976*26.496mm 29.0*34.69*2.6mm 6 CPU(8 Bits) 0.8mmx32pin FPC(Hotbar) 120
1.54" GAIO15NNGL1E0 240*240 27.72*27.72mm 31.5*35.0*2.3mm free SPI 0.5mmx22pin FPC(ZIF) 400
1.54" GAIO15NNGL2E0 240*240 27.72*27.72mm 31.5*35.0*2.3mm free SPI 0.5mmx22pin FPC(ZIF) 400
1.77" GATJ17NNHA2E0 128*160 28.03*35.04mm 34.7*46.7*2.5mm 6 CPU(8 Bits) 1.0mmx20pin FPC(Hotbar) 320
2.0 GAIQ20MNJJ1E0 320*240 40.8*30.6mm 46.0*40.0*3.0mm free SPI 0.5mmx12pin FPC(ZIF) 300
2.0" GAIQ20MNIG2E0 240*320 30.6*40.8mm 35.4*50.8* 2.05mm free SPI 0.5mmx20pin FPC(ZIF) 500
2.13" (mono) GATO21SNIH1E0 122*250 23.668*48.5mm 29.27*58.4* 2.8mm 6 SPI 0.5mmx10pin FPC(ZIF) No BL
2.31" GWTQ23SNGF1E0 320*240 46.75*35.06mm 50.8*45.8*2.3mm 6 CPU(16 Bits) 0.3mmx45pin FPC(ZIF) 300
2.4" GATQ24NNGL1E0 240*320 36.72*48.96mm 42.72*60.16*2.55mm 6 CPU(8080 16/8 Bits) 0.5mmx45pin FPC(ZIF) 350
2.4" GAIQ24MNJH1E0 240*320 36.72*48.96mm 42.72*60.26*2.3mm free CPU(16/8 Bits) 1.0mmx39pin FPC(Hotbar) 300
2.4"+RTP GAIQ24MPJH1R0 240*320 36.72*48.96mm 42.72*60.26*3.4mm free CPU(16/8 Bits) 1.0mmx39pin FPC(Hotbar) 240
2.4"+CTP GAIQ24MCJH1C0 240*320 36.72*48.96mm 42.72*60.26*4.63mm free CPU(16/8 Bits) 1.0mmx39pin FPC(Hotbar) 270
2.4" GAIQ24MNJH2E0 240*320 36.72*48.96mm 42.72*60.26*2.3mm free CPU(16/8 Bits) 0.5mmx45pin FPC(ZIF) 300
2.4"+RTP GAIQ24MPJH2R0 240*320 36.72*48.96mm 42.72*60.26*3.4mm free CPU(16/8 Bits) 0.5mmx45pin FPC(ZIF) 240
2.4"+CTP GAIQ24MCJH2C0 240*320 36.72*48.96mm 42.72*60.26*4.63mm free CPU(16/8 Bits) 0.5mmx45pin FPC(ZIF) 270
2.4"+CTP GATQ24NCGL1C0 240*320 36.72*48.96mm 42.72*60.16*4.88mm 6 CPU(8080 16/8 Bits) 0.5mmx45pin FPC(ZIF) 300
2.4" GATQ24NNGL2E0 240*320 36.72*48.96mm 42.72*60.26*2.55mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 350
2.4"+RTP GATQ24NPGE2R0 240*320 36.72*48.96mm 42.72*60.26*3.65mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 280
2.4"+CTP GATQ24NCGL2C0 240*320 36.72*48.96mm 42.72*60.26*4.88mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 300
2.4" GATQ24NNGL3E0 240*320 36.72*48.96mm 42.72*60.26*2.55mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 350
2.4"+RTP GATQ24NPGE3R0 240*320 36.72*48.96mm 42.72*60.26*3.65mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 280
2.4"+CTP GATQ24NCGL3C0 240*320 36.72*48.96mm 42.72*60.26*4.88mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 300
2.4" GNTQ24SNHG1E0 240*320 36.72*48.96mm 42.72*60.26*2.55mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 450
2.4"+RTP GNTQ24SPHG1R0 240*320 36.72*48.96mm 42.72*60.26*3.65mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 350
2.4"+CTP GNTQ24SCHG1C0 240*320 36.72*48.96mm 42.72*60.26*4.88mm 6 CPU(16 Bits) 1.0mmx39pin FPC(Hotbar) 380
2.8" GATQ28WNGF1E0 240*320 43.2*57.6mm 50.0*69.2*2.2mm 6 CPU(16 Bits) 1.0mmx37pin FPC(Hotbar) 250
2.8"+RTP GATQ28WPGF1R0 240*320 43.2*57.6mm 50.0*69.2*3.3mm 6 CPU(16 Bits) 1.0mmx37pin FPC(Hotbar) 180
2.8"+CTP GATQ28WCGF1C0 240*320 43.2*57.6mm 50.0*69.2*4.08mm 6 CPU(16 Bits) 1.0mmx37pin FPC(Hotbar) 180
2.8" GAIQ28WNJH1E0 240*320 43.2*57.6mm 50.0*69.2*2.4mm free CPU(16 Bits) 1.0mmx37pin FPC(Hotbar) 380
2.8"+RTP GAIQ28WPJH1R0 240*320 43.2*57.6mm 50.0*69.2*3.5mm free CPU(16 Bits) 1.0mmx37pin FPC(Hotbar) 300
2.8"+CTP GAIQ28WCJH1C0 240*320 43.2*57.6mm 50.0*69.2*4.73mm free CPU(16 Bits) 1.0mmx37pin FPC(Hotbar) 330
2.8" GAIQ28WNJH2E0 240*320 43.2*57.6mm 50.0*69.2*2.4mm free CPU(16 Bits) 0.5mmx40pin FPC(ZIF) 380
2.8"+RTP GAIQ28WPJH2R0 240*320 43.2*57.6mm 50.0*69.2*3.5mm free CPU(16 Bits) 0.5mmx40pin FPC(ZIF) 300
2.8"+CTP GAIQ28WCJH2C0 240*320 43.2*57.6mm 50.0*69.2*4.73mm free CPU(16 Bits) 0.5mmx40pin FPC(ZIF) 330
3.5"+CTP GAIQ35MCIF1C0 320*240 70.08*52.56 mm 76.9*63.9*5.08 mm free Parallel RGB-24 bit 0.5mmx54pin FPC(ZIF) 450
3.5" GWTQ35NNF1E0 320*480 48.96*73.44mm 54.66*82.94*2.1mm 6 3-SPI+ 0.3mmx45pin FPC(ZIF) 360
3.5" GWTQ35NNF1E1 320*480 48.96*73.44mm 54.66*82.94*2.1mm 6 4-SPI+ 0.3mmx45pin FPC(ZIF) 360
3.5"+RTP GWTQ35NPHH1R0 320*480 48.96*73.44mm 54.66*82.94*3.4mm 6 4-SPI+ 0.3mmx45pin FPC(ZIF) 360
3.5"+CTP GWTQ35NCHH1C0 320*480 48.96*73.44mm 54.66*82.94*3.5mm 6 4-SPI+ 0.3mmx45pin FPC(ZIF) 360
3.5" GWTQ35NNF1E2 320*480 48.96*73.44mm 54.66*82.94*2.1mm 6 i80 8bit (DB0-DB7) 0.3mmx45pin FPC(ZIF) 360
3.5" GATQ35NNJH1E0 320*480 48.96*73.44mm 54.66*82.94*2.1mm 6 MIPI 0.3mmx19pin FPC(ZIF) 360
3.5" GAIQ35MNIF1E0 320*240 70.08*52.56 mm 76.9*63.9*3.15 mm free Parallel RGB-24 bit 0.5mmx54pin FPC(ZIF) 500
3.5"+RTP GAIQ35MPIF1R0 320*240 70.08*52.56 mm 76.9*63.9*4.25 mm free Parallel RGB-24 bit 0.5mmx54pin FPC(ZIF) 400
3.5" GKTQ35SNAA1E0 320*240 70.08*52.56 mm 76.9*63.9*3.3 mm 12 8 Bits i80 system 0.5mmx36pin FPC(ZIF) 300
3.5"+RTP GVTQ35SPAF1R0 320*240 70.08*52.56 mm 76.9*63.9*4.4 mm 12 8 Bits i80 system 0.5mmx36pin FPC(ZIF) 240
3.5"+RTP GVTQ35SPAF1R1 320*240 70.08*52.56 mm 76.9*63.9*4.4 mm 12 8 Bits i80 system 0.5mmx36pin FPC(ZIF) 240
3.5"+CTP GKTQ35SCAA1C0 320*240 70.08*52.56 mm 76.9*63.9*5.23 mm 12 8 Bits i80 system 0.5mmx36pin FPC(ZIF) 270
3.5"+RTP GKTQ35SPAK1R0 320*240 70.08*52.56 mm 76.9*63.9*4.4 mm 12 16 Bits i80 system 0.5mmx36pin FPC(ZIF) 240
3.5"+RTP GKTQ35SP9E1R0 320*240 70.08*52.56 mm 76.9*63.9*4.4 mm 12 16 Bits i68 system 0.5mmx36pin FPC(ZIF) 240
3.5" GKTQ35SNAG1E0 320*240 70.08*52.56 mm 76.9*63.9*3.3 mm 12 8 Bits i68 system 0.5mmx36pin FPC(ZIF) 300
3.5"+RTP GKTQ35SPAH2R0 320*240 70.08*52.56 mm 76.9*63.9*4.4 mm 12 8 Bits i68 system 0.5mmx36pin FPC(ZIF) 240
3.5" GKTQ35SNBL1E0 320*240 70.08*52.56 mm 76.9*63.9*3.3 mm 12 8 Bits i68 system 0.5mmx36pin FPC(ZIF) 800
3.5" GKTQ35SNBL2E0 320*240 70.08*52.56 mm 76.9*63.9*3.3 mm 12 8 Bits i80 system 0.5mmx36pin FPC(ZIF) 300
3.5"+RTP GKTQ35SPBK1R0 320*240 70.08*52.56 mm 76.9*63.9*4.4 mm 12 8 Bits i68 system 0.5mmx36pin FPC(ZIF) 640
3.5" GKTQ35SNBL1H0 320*240 70.08*52.56 mm 76.9*63.9*3.3 mm 12 8 Bits i80 system 0.5mmx36pin FPC(ZIF) 800
3.5"(TW) GKIQ35MNIJ1A0 320*240 70.08 x 52.56 76.9 x 63.9 x 3.15 free Parallel RGB-24bit 0.5mm x 54pin FPC 1000
3.5"(TW) GKIQ35MNJG1A0 320*240 70.08 x 52.56 76.9 x 63.9 x 3.15 free Parallel RGB-24bit 0.5mm x 54pin FPC 300
